GR712RC On Board Computer Reference Design

We have developed a reference design for an onboard computer based on the GR712RC. The design has been adopted in the JUICE mission and has been used in seven out of the ten JUICE science instruments.

The reference design data package consists of schematics and other design files required for developing an on board computer for flight. The reference design includes:

• Schematics & EEE Parts lists
• Assembly Drawings
• Hardware design description
• Failure Mode and Effects Analysis
• Timing Analysis
• Radiation Analysis report
• Worst Case Analysis

Compressed folders with all the design files are available for download.

‍

Please check the disclaimer file before downloading the package.

Contact sales@gaisler.com for the password

‍
